Destination Filtering

The destination filtering mechanism lets you select a default behavior for every file and more specifically at publish time the storages that will be delivered.

Filter Mechanism Description

A general boolean switch syncEverywhere in rsyncGlobalParameters tells the default behavior of the synchronisation for every files:

{
    "_id": "rsyncGlobalParameters",
    "syncEverywhere": true
}

• true will synchronise the files everywhere by default
• false disables synchronisation by default

The default behavior can be overridden for each file, setting the syncEverywhere key to the desired boolean value directly on the files' records:

{
    "_id": "/filepath",
    "origin": "storage1",
    "syncEverywhere": false
}

This won't synchronise this specific file anywhere. You can then specify the storages that will receive the file using the sync_<storagename> boolean switches:

{
    "_id": "/filepath",
    "origin": "storage1",
    "sync_storage4": true,
    "syncEverywhere": false
}

Using the same method, you can remove a storage from the expected destinations specifying false in the sync_<storagename> key:

{
    "_id": "/filepath",
    "origin": "storage1",
    "sync_storage4": false
}

This will synchronise this file on every storages but storage4.

Verify Waiting Lists

The tracker has 2 operations /api/listup and /api/listdown to evaluate and communicate to the agents the next elements to transfer. Get 10 elements to upload from source to target:

https://trackername.syncplanet.io/api/listup/source/target/10

Get 10 elements to download from source to target:

https://trackername.syncplanet.io/api/listdown/source/target/10

Notes

Depending on your synchronisation setup, some storages may behave like hubs to other sites:

storage1 -> storage2 -> storage3

This means that the storage2 must get a file in order to transfer this file to storage3. Therefore you must set the keys accordingly.

The mechanism was described in this issue.
